Neodymium Block Magnet 50x10x10mm N35
Product code: B-W10H10L50-N35
Prices are VAT Incl.
Volume pricing available on requestAustralia's Leading Supplier
Shipping Worldwide*
30 Day Returns
Same Day Dispatch*
Magnetic Product Description:
This neodymium magnetic block has a length of 50mm, width of 10mm and a height of 10mm. It has a pull force of 14.4 kilos. It is identified by the AMF magnet part number B-W10H10L50-N35.
Uses for our rare earth block magnets:
Neodymium Bar magnets are well suited to applications where ferrous metal contaminants need to be separated or removed from non-ferrous material. This separation is often achieved by passing the bar magnet over material to attract and remove ferrous contaminants. However these are generally not stand alone magnets but rather block magnets that have been enclosed into a device such as a swarf cleaner to provide an efficient means of use.
Magnets themselves are quite a brittle material and enclosing them within a device or a metal housing allows them to withstand regular use. Block magnets are often used in combination to create a long field of magnetism, an example of this type of arrangement is a knife holder or tool holder. The rod magnets are placed end to end to create a magnetic surface which is much longer than an individual magnet could be made. Some types of magnetic equipment have a self-cleaning function so the metal can be disposed of in a safe, hands-free manner. This is achieved by having a mechanical means of distancing the magnet away from the active surface of the metal housing to release the metal debris that has been magnetically attracted.
No FAQ available
NB: Ranges are indicative for product category, please check individual products for specic values within that range.
The most common coating for Neodymium magnets is Nickel + Copper + Nickel (Ni + Cu + Ni). This coating offers the magnet relatively good protection from corrosion and passive applications. If the magnet will be exposed to moisture or liquid then consider the use of an organic coating such as Epoxy. A hard wearing coating, Epoxy is suited to applications where the magnet will come under some friction or knocking.
Magnets are readily available in Blocks, Discs, Cylinders & Rings. AMF Magnetics specializes in the supply of short-run prototype magnets including Arc Segments, various magnetic orientations etc. If you need a magnet size that we don't carry in stock, submit a Design-a-Magnet enquiry for a quote on your custom magnet design.
Neodymium magnets are offered in several different grades. The first section N30-54 has an operating temperature of up to 80 degrees. Most of our stock only goes up to N38. The second section, denoted with the "M" prefix after the grade has an operating temperature 100 degrees. After this the grades are "H", "SH", "UH" & "EH". In order for the magnet to withstand a higher operating temperature, during production more of the raw material PrNd is incorporated as these elements have a naturally occurring resistance to high temperatures.
